Effects of Internal Yaw-Vectoring Devices on the Static Performance of a Pitch-Vectoring Nonaxisymmetric Convergent-Divergent Nozzle

Effects of Internal Yaw-Vectoring Devices on the Static Performance of a Pitch-Vectoring Nonaxisymmetric Convergent-Divergent Nozzle


     0
5
4
3
2
1



Out of Stock


Notify me when this book is in stock
X
About the Book

An investigation was conducted in the static test facility of the Langley 16-Foot Transonic Tunnel to evaluate the internal performance of a nonaxisymmetric convergent divergent nozzle designed to have simultaneous pitch and yaw thrust vectoring capability. This concept utilized divergent flap deflection for thrust vectoring in the pitch plane and flow-turning deflectors installed within the divergent flaps for yaw thrust vectoring. Modifications consisting of reducing the sidewall length and deflecting the sidewall outboard were investigated as means to increase yaw-vectoring performance. This investigation studied the effects of multiaxis (pitch and yaw) thrust vectoring on nozzle internal performance characteristics. All tests were conducted with no external flow, and nozzle pressure ratio was varied from 2.0 to approximately 13.0. The results indicate that this nozzle concept can successfully generate multiaxis thrust vectoring. Deflection of the divergent flaps produced resultant pitch vector angles that, although dependent on nozzle pressure ratio, were nearly equal to the geometric pitch vector angle. Losses in resultant thrust due to pitch vectoring were small or negligible. The yaw deflectors produced resultant yaw vector angles up to 21 degrees that were controllable by varying yaw deflector rotation. However, yaw deflector rotation resulted in significant losses in thrust ratios and, in some cases, nozzle discharge coefficient. Either of the sidewall modifications generally reduced these losses and increased maximum resultant yaw vector angle. During multiaxis (simultaneous pitch and yaw) thrust vectoring, little or no cross coupling between the thrust vectoring processes was observed. Asbury, Scott C. Langley Research Center CONVERGENT-DIVERGENT NOZZLES; DEFLECTORS; FLAPS (CONTROL SURFACES); NOZZLE FLOW; PITCH (INCLINATION); PROPULSION SYSTEM PERFORMANCE; STATIC TESTS; THRUST VECTOR CONTROL; WIND TUNNEL TESTS; YAW; DISCHARGE COEFFICIENT; NOZZLE INSERTS; ...


Best Sellers


Product Details
  • ISBN-13: 9781723039362
  • Publisher: Createspace Independent Publishing Platform
  • Publisher Imprint: Createspace Independent Publishing Platform
  • Height: 279 mm
  • No of Pages: 118
  • Spine Width: 6 mm
  • Width: 216 mm
  • ISBN-10: 1723039365
  • Publisher Date: 17 Jul 2018
  • Binding: Paperback
  • Language: English
  • Returnable: N
  • Weight: 290 gr
